Greenpedel G500S 350W 500W 750W High Torque Fat Tire Gear Hub Motor

Greenpedel G500 Serial motor is powerful geared motor ,specially for fat bike.we have front ,rear and rear cassette drive for option.the power can be made from 350W-750W.speed can reach to 42KM/H with 26" wheel.

Model:
GP-G500S
Brand:
Green pedel
Voltage:
36V 48V
Power:
350W-750W
Type:
Geared hub motor

Availability:



Inquire

Specification

	Rated voltage 36V/48V	Net weight 4.2KG
	Max no-load speed 370RPM	Noise <60db
	Rated power 350W-750W	Working temperature -20℃-45℃
	Max loading speed 320RPM	Cable location shaft center right
	Efficiency ≥80%	Reduction radio 5.0
	Waterproof grade IP54	Anti-corrosion grade 96
	Fitting wheel size 16"-28"(700C)	Brake type Roller brake
	Fork size 135mm for front wheel/180-190mm fro rear wheel	Spoke holes *36H12G/13G**

Our hub motors are all brushless motors, which can be divided into two categories: gear motors and DC motors.

Gear motors are small size, light weight, large torque, small running current, power-saving, low motor noise, but the power is low and slow. Therefore, gear motors are generally used for 250w-750w motors.

While DC motors have large torque, fast speed and large power, because there is no gear system, and less motor damage is caused. But the size is large, heavy and consumes power, so we usually use DC motor for 750w-3000w motor.
