Greenpedel D27 36V 48V 500W 750W Electric Bike Ebike Motor

Greenpedel BLDC 500W-750W hub motor for electric bike,maxed speed can reach to 42KM/H with max torque more than 50N.M.silent and powerful .people can use it for offroad , or limited the power and speed to 250W/25KM/H and use it for road legal.

Model:
GP-D27
Brand:
Green pedel
Voltage:
36V 48V
Power:
500W-750W
Type:
BLDC hub motor

Availability:



Inquire

Specification

	Rated voltage 36V/48V	Net weight 6KG
	Max no-load speed 425RPM	Noise <60db
	Rated power 500W-750W	Working temperature -20℃-45℃
	Max loading speed 375RPM	Cable location shaft center right
	Efficiency ≥78%	Quantity of the magnets 46
	Waterproof grade IP54	Anti-corrosion grade 96
	Fitting wheel size 16"-28"(700C)	Brake type V brake/disc brake
	Fork size 100mm for front wheel/135mm fro rear wheel	Spoke holes 12G/13G

Our hub motors are all brushless motors, which can be divided into two categories: gear motors and DC motors.

Gear motors are small size, light weight, large torque, small running current, power-saving, low motor noise, but the power is low and slow. Therefore, gear motors are generally used for 250w-750w motors.

While DC motors have large torque, fast speed and large power, because there is no gear system, and less motor damage is caused. But the size is large, heavy and consumes power, so we usually use DC motor for 750w-3000w motor.
